MODEL | LDP50C(L) |
Suction / Discharge port dia (mm) | 50(2") |
Max. Capacity (m3 / hr) | 21 |
Max. Head (m) | 26 |
Engine Speed (rpm) | 3000 |
Self-priming time (s / 4m) | 70 |
Max. Suction Head (m) | 8 |
Engine Model | LA170FP |
Engine Cont. output (hp) | 3.8 |
Engine Displacement (cc) | 211 |
Fuel Tank Capacity (L) | C=2.5 |
CL=12.5 | |
Unit Net Weight (kg) | C=38 |
CL=41 | |
Unit Dimensions(L x W x H) (mm) | C=475*400*500 |
CL=475*455*615 | |
