MODEL | LDP100C(L) |
Suction / Discharge port dia (mm) | 100(4") |
Max. Capacity (M3 / hr) | 96 |
Max. Head (m) | 25 |
Engine Speed (rpm) | 3000 |
Self-priming time (s / 4m) | 180 |
Max. Suction Head (m) | 8 |
Engine Model | LA186FP |
Engine Cont. output (hp) | 7.7 |
Engine Displacement (cc) | 406 |
Fuel Tank Capacity (L) | C=5.5 |
CL=12.5 | |
Unit Net Weight (kg) | C=67 |
CL=70 | |
Unit Dimensions(L x W x H) (mm) | C=645*475*605 |
CL=645*475*725 | |
